Contour Lines

/**
 * VibeBox Motion · Contour Lines
 * Copyright (c) 2026 VibeBox. Licensed under the VibeBox Motion Free License:
 * https://motion.vibeboxph.com/license
 * Use it in unlimited personal, commercial and client projects.
 * Do not sell or redistribute it as a component, kit, template or builder.
 */
"use client";

import type { ReactNode } from "react";
import { BackdropCanvas, type PosterSpec } from "@/lib/vibebox/backdrop-canvas";
import { contourLinesPiece, presets, type ContourLinesPreset } from "./contour-lines.shader";

export type ContourLinesColor = "paper" | "line" | "index" | "tint";
export type ContourLinesValue = "levels" | "scaleC" | "width" | "shade";

export type ContourLinesProps = {
  /** What sits on the scene: a heading, a call to action, a whole section. */
  children?: ReactNode;
  /** A named look: `charcoal`, `blueprint`, `sand`, `steel`, `forest`. */
  preset?: ContourLinesPreset;
  /** Overrides single palette colours with any CSS colour. */
  colors?: Partial<Record<ContourLinesColor, string>>;
  /** Multiplies the preset's speed (1 keeps it, 0 holds the scene still). */
  speed?: number;
  /** Multiplies the preset's brightness. */
  intensity?: number;
  /** The pointer and touch move the scene. */
  interactive?: boolean;
  /** Accessible name; leave it out when the scene is only a background. */
  label?: string;
  /** Hold one still frame until this is false (for a gallery card). */
  still?: boolean;
  className?: string;
} & Partial<Record<ContourLinesValue, number>>;

const POSTER: PosterSpec = { type: "linear", from: "paper", to: "tint", angle: 135 };

export function ContourLines({ children, preset, colors, speed, intensity, interactive = true, label, still, className, levels, scaleC, width, shade }: ContourLinesProps) {
  return (
    <BackdropCanvas
      slug="contour-lines"
      piece={contourLinesPiece}
      presets={presets}
      fallback="charcoal"
      preset={preset}
      colors={colors}
      values={{ levels, scaleC, width, shade }}
      speed={speed}
      intensity={intensity}
      poster={POSTER}
      scale={0.5}
      stillTime={3}
      still={still}
      interactive={interactive}
      label={label}
      className={className}
    >
      {children}
    </BackdropCanvas>
  );
}

/**
 * VibeBox Motion · Contour Lines
 * Copyright (c) 2026 VibeBox. Licensed under the VibeBox Motion Free License:
 * https://motion.vibeboxph.com/license
 * Use it in unlimited personal, commercial and client projects.
 * Do not sell or redistribute it as a component, kit, template or builder.
 */
import { compose, createScenePiece, type ScenePreset } from "@/lib/vibebox/engine/backdrops";

/*
 * A survey map: a slowly shifting height field drawn as contour lines, every fifth one heavier,
 * over soft hill shading. The line width is measured in pixels with screen-space derivatives, so
 * it stays crisp at any size. The pointer raises a small hill under it.
 */

const SCENE = /* glsl */ `
uniform vec3 uPaper;
uniform vec3 uLine;
uniform vec3 uIndex;
uniform vec3 uTint;
uniform float uLevels;
uniform float uScaleC;
uniform float uWidth;
uniform float uShade;
uniform float uSpeed;
uniform float uIntensity;

float T;
vec2 pointerP;

float heightAt(vec2 p) {
  float h = fbm(p * uScaleC + vec2(T * 0.02, -T * 0.015));
  h = h * 0.85 + 0.15 * vnoise(p * uScaleC * 0.4 + 7.0);
  float d = length(p - pointerP);
  h += uHover * 0.22 * exp(-d * d * 5.0);
  return h;
}

void main() {
  vec2 uv = centred(gl_FragCoord.xy);
  T = uTime * uSpeed;
  float aspect = uResolution.x / uResolution.y;
  pointerP = vec2((uPointer.x - 0.5) * aspect, uPointer.y - 0.5);
  float h = heightAt(uv);
  float f = h * uLevels;

  // Distance to the nearest contour, in pixels.
  float w = max(fwidth(f), 1e-4);
  float dist = abs(fract(f - 0.5) - 0.5) / w;
  float line = 1.0 - smoothstep(uWidth * 0.5, uWidth * 0.5 + 1.0, dist);
  // Every fifth contour is an index line.
  float idx = mod(floor(f + 0.5), 5.0) < 0.5 ? 1.0 : 0.0;
  float indexLine = (1.0 - smoothstep(uWidth * 0.9, uWidth * 0.9 + 1.0, dist)) * idx;

  // Hill shading from the slope.
  vec2 g = vec2(dFdx(h), dFdy(h)) * uResolution.y * 0.35;
  float shade = clamp(0.5 + dot(g, normalize(vec2(-0.6, 0.8))) * 2.0, 0.0, 1.0);

  vec3 col = lin(uPaper);
  col = mix(col, lin(uTint), smoothstep(0.35, 0.8, h) * 0.55);
  col *= mix(1.0, 0.72 + 0.5 * shade, uShade);
  col = mix(col, lin(uLine), clamp(line, 0.0, 1.0) * 0.75);
  col = mix(col, lin(uIndex), clamp(indexLine, 0.0, 1.0));

  col *= uIntensity;
  col *= 1.0 - 0.18 * smoothstep(0.6, 1.2, length(uv * vec2(0.85, 1.1)));
  fragColor = vec4(finish(col, gl_FragCoord.xy), 1.0);
}
`;

export const fragment = compose(SCENE);

export const PRESET_NAMES = ["charcoal", "blueprint", "sand", "steel", "forest"] as const;
export type ContourLinesPreset = (typeof PRESET_NAMES)[number];

export const presets: Record<ContourLinesPreset, ScenePreset> = {
  charcoal: {
    colors: { paper: "#0b0d12", line: "#5d6578", index: "#cfd6e6", tint: "#1b2236" },
    values: { levels: 22, scaleC: 1.6, width: 1.1, shade: 0.5, speed: 0.6, intensity: 1 },
  },
  blueprint: {
    colors: { paper: "#0f3a8a", line: "#6fa3ff", index: "#ffffff", tint: "#1450c0" },
    values: { levels: 26, scaleC: 1.5, width: 1.1, shade: 0.35, speed: 0.5, intensity: 1 },
  },
  sand: {
    colors: { paper: "#f1e6cf", line: "#b89868", index: "#7a5a2c", tint: "#e0cca4" },
    values: { levels: 20, scaleC: 1.5, width: 1.2, shade: 0.7, speed: 0.4, intensity: 1 },
  },
  steel: {
    colors: { paper: "#c9d1da", line: "#7c8794", index: "#2a323d", tint: "#aeb9c5" },
    values: { levels: 24, scaleC: 1.7, width: 1.1, shade: 0.6, speed: 0.5, intensity: 1 },
  },
  forest: {
    colors: { paper: "#0c1f17", line: "#2f6b4d", index: "#9fe0b8", tint: "#123826" },
    values: { levels: 22, scaleC: 1.6, width: 1.1, shade: 0.5, speed: 0.55, intensity: 1 },
  },
};

export const contourLinesPiece = createScenePiece("contour-lines", fragment);

/**
 * VibeBox Motion · Contour Lines
 * Copyright (c) 2026 VibeBox. Licensed under the VibeBox Motion Free License:
 * https://motion.vibeboxph.com/license
 * Use it in unlimited personal, commercial and client projects.
 * Do not sell or redistribute it as a component, kit, template or builder.
 */
export { ContourLines, type ContourLinesProps, type ContourLinesColor, type ContourLinesValue } from "./contour-lines.client";
export { PRESET_NAMES as CONTOUR_LINES_PRESETS, presets as contourLinesPresets, type ContourLinesPreset } from "./contour-lines.shader";
