Grid Horizon

/**
 * VibeBox Motion · Grid Horizon
 * Copyright (c) 2026 VibeBox. Licensed under the VibeBox Motion Free License:
 * https://motion.vibeboxph.com/license
 * Use it in unlimited personal, commercial and client projects.
 * Do not sell or redistribute it as a component, kit, template or builder.
 */
"use client";

import type { ReactNode } from "react";
import { BackdropCanvas, type PosterSpec } from "@/lib/vibebox/backdrop-canvas";
import { gridHorizonPiece, presets, type GridHorizonPreset } from "./grid-horizon.shader";

export type GridHorizonColor = "skyTop" | "skyLow" | "sunA" | "sunB" | "grid" | "ground";
export type GridHorizonValue = "horizonG" | "sunSize" | "cells" | "bank";

export type GridHorizonProps = {
  /** What sits on the scene: a heading, a call to action, a whole section. */
  children?: ReactNode;
  /** A named look: `synthwave`, `arcade`, `ice`, `ember`. */
  preset?: GridHorizonPreset;
  /** Overrides single palette colours with any CSS colour. */
  colors?: Partial<Record<GridHorizonColor, string>>;
  /** Multiplies the preset's speed (1 keeps it, 0 holds the scene still). */
  speed?: number;
  /** Multiplies the preset's brightness. */
  intensity?: number;
  /** The pointer and touch move the scene. */
  interactive?: boolean;
  /** Accessible name; leave it out when the scene is only a background. */
  label?: string;
  /** Hold one still frame until this is false (for a gallery card). */
  still?: boolean;
  className?: string;
} & Partial<Record<GridHorizonValue, number>>;

const POSTER: PosterSpec = { type: "horizon", top: "skyTop", horizon: "skyLow", groundTop: "ground", groundBottom: "ground", at: 52, glow: "sunA", glowAt: [50, 48] };

export function GridHorizon({ children, preset, colors, speed, intensity, interactive = true, label, still, className, horizonG, sunSize, cells, bank }: GridHorizonProps) {
  return (
    <BackdropCanvas
      slug="grid-horizon"
      piece={gridHorizonPiece}
      presets={presets}
      fallback="synthwave"
      preset={preset}
      colors={colors}
      values={{ horizonG, sunSize, cells, bank }}
      speed={speed}
      intensity={intensity}
      poster={POSTER}
      scale={0.5}
      stillTime={2.4}
      still={still}
      interactive={interactive}
      label={label}
      className={className}
    >
      {children}
    </BackdropCanvas>
  );
}

/**
 * VibeBox Motion · Grid Horizon
 * Copyright (c) 2026 VibeBox. Licensed under the VibeBox Motion Free License:
 * https://motion.vibeboxph.com/license
 * Use it in unlimited personal, commercial and client projects.
 * Do not sell or redistribute it as a component, kit, template or builder.
 */
import { compose, createScenePiece, type ScenePreset } from "@/lib/vibebox/engine/backdrops";

/*
 * A plane of light running to a horizon: a perspective grid that scrolls toward the viewer under
 * a striped sun and a row of faceted mountains. Line width is kept constant on screen, so the
 * far grid fades into a glow instead of shimmering. The pointer banks the grid sideways.
 */

const SCENE = /* glsl */ `
uniform vec3 uSkyTop;
uniform vec3 uSkyLow;
uniform vec3 uSunA;
uniform vec3 uSunB;
uniform vec3 uGrid;
uniform vec3 uGround;
uniform float uHorizonG;
uniform float uSunSize;
uniform float uCells;
uniform float uBank;
uniform float uSpeed;
uniform float uIntensity;

float T;

float mountains(float x) {
  float h = ridged(vec2(x * 1.7 + 4.0, 1.0)) * 0.12 + ridged(vec2(x * 4.3, 7.0)) * 0.03;
  return h;
}

void main() {
  vec2 uv = centred(gl_FragCoord.xy);
  T = uTime * uSpeed;
  float aspect = uResolution.x / uResolution.y;
  float hy = uHorizonG;
  float bank = (uPointer.x - 0.5) * uBank * (0.3 + uHover * 0.7);

  vec3 col;
  if (uv.y > hy) {
    // Sky: a gradient, the sun with its slats, and a haze at the horizon.
    float t = clamp((uv.y - hy) / 0.6, 0.0, 1.0);
    col = lin(mix(uSkyLow, uSkyTop, pow(t, 0.7)));
    vec2 sc = vec2(0.0, hy + 0.17 * uSunSize + 0.02);
    float sr = 0.2 * uSunSize;
    float d = length((uv - sc) * vec2(1.0, 1.0));
    float disc = smoothstep(sr + 0.004, sr - 0.004, d);
    // Slats: bands cut out of the lower half, wider toward the bottom.
    float local = (sc.y - uv.y) / sr;           // 0 at the middle, 1 at the bottom of the disc
    float cut = local > 0.0 ? smoothstep(0.5, 0.52, fract(local * 7.0 - T * 0.05) ) * smoothstep(0.0, 0.35, local) : 0.0;
    disc *= 1.0 - cut * 0.92;
    vec3 sun = mix(lin(uSunA), lin(uSunB), clamp(local * 0.5 + 0.5, 0.0, 1.0));
    col = mix(col, sun * 1.4, disc);
    col += lin(uSunA) * exp(-max(d - sr, 0.0) * 5.0) * 0.28;
    // Mountains: a dark silhouette with a bright rim.
    float m = hy + mountains(uv.x + bank * 0.2);
    float mi = smoothstep(m + 0.003, m - 0.003, uv.y);
    float rim = smoothstep(0.012, 0.0, abs(uv.y - m)) ;
    col = mix(col, lin(uGround) * 0.9, mi);
    col += lin(uGrid) * rim * 0.8;
  } else {
    // The plane: depth runs as 1 / distance below the horizon.
    float dy = hy - uv.y;
    float z = 0.18 / max(dy, 0.002);
    float k = uCells * 6.0;
    float x = (uv.x - bank * dy * 2.0) * z * k;
    float zz = z * k * 0.5 + T * 1.2;
    vec2 g = vec2(x, zz);
    vec2 w = fwidth(g);
    vec2 l = abs(fract(g - 0.5) - 0.5) / max(w, 1e-4);
    float line = 1.0 - clamp(min(l.x, l.y) - 0.5, 0.0, 1.0);
    // Far away the lines are narrower than a pixel; let them melt into a glow instead.
    float far = smoothstep(0.0, 0.1, dy);
    vec3 ground = lin(uGround);
    col = ground * (0.7 + 0.5 * smoothstep(0.35, 0.0, dy));
    col += lin(uGrid) * line * far * 1.1;
    col += lin(uGrid) * exp(-dy * 22.0) * 0.55;
    col += lin(uSunA) * exp(-dy * 9.0) * 0.12;
  }

  col *= uIntensity;
  col *= 1.0 - 0.3 * smoothstep(0.55, 1.2, length(uv * vec2(0.8, 1.1)));
  fragColor = vec4(finish(col, gl_FragCoord.xy), 1.0);
}
`;

export const fragment = compose(SCENE);

export const PRESET_NAMES = ["synthwave", "arcade", "ice", "ember"] as const;
export type GridHorizonPreset = (typeof PRESET_NAMES)[number];

export const presets: Record<GridHorizonPreset, ScenePreset> = {
  synthwave: {
    colors: { skyTop: "#0c0624", skyLow: "#6a1b9a", sunA: "#ff3fa4", sunB: "#ffd23f", grid: "#38d4ff", ground: "#0a0420" },
    values: { horizonG: 0.04, sunSize: 1, cells: 1.2, bank: 1, speed: 0.9, intensity: 1.05 },
  },
  arcade: {
    colors: { skyTop: "#050818", skyLow: "#1b2a6a", sunA: "#35d8ff", sunB: "#ff4fb6", grid: "#ff4fb6", ground: "#04061a" },
    values: { horizonG: 0.02, sunSize: 0.9, cells: 1.4, bank: 1, speed: 1.1, intensity: 1.05 },
  },
  ice: {
    colors: { skyTop: "#0a1e3a", skyLow: "#7fc6ff", sunA: "#ffffff", sunB: "#bfe9ff", grid: "#bfe9ff", ground: "#06121f" },
    values: { horizonG: 0.05, sunSize: 0.8, cells: 1.1, bank: 0.8, speed: 0.7, intensity: 1.05 },
  },
  ember: {
    colors: { skyTop: "#14060a", skyLow: "#8a1f2a", sunA: "#ff7a2a", sunB: "#ffd36a", grid: "#ff7a2a", ground: "#0c0406" },
    values: { horizonG: 0.04, sunSize: 1.1, cells: 1.2, bank: 1, speed: 0.8, intensity: 1.05 },
  },
};

export const gridHorizonPiece = createScenePiece("grid-horizon", fragment);

/**
 * VibeBox Motion · Grid Horizon
 * Copyright (c) 2026 VibeBox. Licensed under the VibeBox Motion Free License:
 * https://motion.vibeboxph.com/license
 * Use it in unlimited personal, commercial and client projects.
 * Do not sell or redistribute it as a component, kit, template or builder.
 */
export { GridHorizon, type GridHorizonProps, type GridHorizonColor, type GridHorizonValue } from "./grid-horizon.client";
export { PRESET_NAMES as GRID_HORIZON_PRESETS, presets as gridHorizonPresets, type GridHorizonPreset } from "./grid-horizon.shader";
